Transmitator de greutate TLM8 CANOPEN.
Transmitator de greutate TLM8 CANOPEN.
Producator: Laumas
Documentație
Descriere
| Weight transmitter with backlit graphic LCD display, 60×32 mm, 128×64 pixels. Four-key keypad for the system calibration. TEST key for direct access to the diagnostic functions. Dimensions: 148 x 92 x 60 mm. | |
The TLM8 offers the benefits and performance of an advanced digital weighing system even using analog load cells. 8 independent reading channels for load cells. Digital equalization. Automatic diagnostics.
- 16-bit Analog output: 0/4-20 mA; 0-5/10 V
- Slave CANopen port, max 99 instruments
- RS485 port (Modbus RTU/Laumas ASCII protocol)
- 3 logic inputs, 5 relay outputs
- OIML R76:2006 approved, class III, 10000 divis. 0.2μV/VSI
- Mounting on Omega/DIN rail for back panel or junction box
- 8 channels A/D converter – 24bit (16000000 points) 4.8 kHz
- Display range 999999
