Platforma cantarire PBI inox Mărește

Platforma cantarire PBI inox

New product

Producator: Dini Argeo - Italia

Capacitate: 6kg, 15kg, 30kg, 60kg, 150kg, 300Kg
Omologare: Disponibila in variante neomologate si omologate
Dimensiune: 300x300mm, 330x330mm, 400x400mm, 600x600mm
Material platan: Inox
Celule sarcina: O celula

Cerere oferta

More details

Informații

TECHNICAL FEATURES
  • Functions with a “single point” 350 Ohm aluminium load cell, in stainless steel hermetic cover, approved according to OIML R60 C3 standards (3000 divisions), IP65 protection degree.
  • Stainless steel tubular structure, with adjustable resting feet and level.
  • Fitted with stainless steel loading surface.
  • Up to 15 Vdc power supply.
  • Shielded cable for connection to the indicator.
  • Upon request:
    - platform calibration service with weight indicator;
    - 3000e CE-M approval, to be combined always to the calibration service;
    - support column for indicator.

Weighing platform: Available versions

Code		 l x w x h
(mm)		 Max
(kg)		 d
(g)		 CE-M*
3000e (g)
 PBTI6 300x300x130 6 2 2
 PBTI15 300x300x130 15 5 5
 PBTI30 300x300x130 30 10 10
 PBQI30 400x400x140 30 10 10
 PBQI60 400x400x140 60 20 20
 PBQI150 400x400x140 150 50 50
 PBXI60 600x600x150 60 20 20
 PBXI150 600x600x150 150 50 50
 PBXI300 600x600x150 300 100 100

 (*) CE-M divisions are obtainable only with the relative options.

Calibration service with weight indicator
  Code Description
DINICAL1 Calibration service for platform up to 30 kg, connected to Dini Argeo weight indicator - NET PRICE
DINICAL2 Calibration service for platform from 31 to 1500 kg, connected to Dini Argeo weight indicator - NET PRICE
Legal for trade approval , class III or IIII, with Dini Argeo indicator (only at time of order)
  Code Description
ECEM CE-M Single platform legal for trade approval.
Attached columns
  Code Description
PBICL350 Support column and fixing bracket for DFWL, DFWLI, DFWLKI series Dini Argeo indicators and AFW, ILW series Scale House indicators, in stainless steel, h= 350 mm, for mounting attached to the "PBI" series platforms.
PBICL500 Support column and fixing bracket for DFWL, DFWLI, DFWLKI series Dini Argeo indicators and AFW, ILW series Scale House indicators, in stainless steel, h= 500 mm, for mounting attached to the "PBI" series platforms.
PBICL700 Support column and fixing bracket for DFWL, DFWLI, DFWLKI series Dini Argeo indicators and AFW, ILW series Scale House indicators, in stainless steel, h= 700 mm, for mounting attached to the "PBI" series platforms.
PBSTF Fixing bracket for mounting the DFWL series indicator attached to the PB and PBI series platforms.
PBISTF Fixing bracket for mounting the DFWLI series indicator attached to the PB and PBI series platforms.
Floor columns
  Code Description
CSP38I-1 Stainless steel column 450x450mm, h=917mm, Ø 38mm. For the indicators of the DINI ARGEO and SCALE HOUSE range.
CSP38D Stainless steel column 350x350mm, h=750mm. Painted steel base, for the indicators of the DINI ARGEO and SCALE HOUSE range.
KWR10 Kit of 4 rubber wheels and galvanized steel frame for CSP column. A pair of idler wheels and a pair with brakes.
Calibration service with Dini Argeo indicator (only at time of order)
  Code Description
CT4 ISO 17025 calibration certificate from 6 to 60 kg. For precision and industrial scales, crane scales.
CT5 ISO 17025 calibration certificate from 61 to 300 kg. For precision and industrial scales, crane scales.

CARACTERISTICI TEHNICE

Funcții cu un "punct unic" 350 OHm celulă de sarcină din aluminiu, în capac inox ermetic, aprobat în conformitate cu standardele OIML R60 C3 (3000 diviziuni), IP65 Grad de protecție.
Structură din oțel inoxidabil tubular, cu picioarele de odihnă reglabile și nivelat.
Echipat cu suprafață de încărcare din oțel inoxidabil.
Până la 15 Vdc sursa de alimentare.
Cablu ecranat pentru conectarea la indicator.
La cerere:
- Serviciu de calibrare platformă cu indicator de greutate;
- Omologare 3000e CE-M, care urmează să fie combinate mereu la serviciul de calibrare;
- Coloana suport pentru indicator.
